VisionWorks In-Dash Wired Rear Observation Camera Integration Kit for Select Ford and Dodge Trucks

VisionWorks
Out of stock
$563.00

Payment details

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa

Help your customers identify what payments are accepted by your store.

The VisionWorks In-Dash WIRED Rear Observation Camera Kit for Trailers is compatible with select Ford & Ram trucks  If your Ford Super Duty truck (2017 - current) or Ram (2020 - current) has a 12 pin outlet above the 7 way plug (as shown in top left corner in photo to the left) and has a Sync 3 w/ 8" screen or Sync 4 w/ 12" screen or Uconnect w/ 8.4 or 12" screen, the truck may be a candiate for this system.  (please refer to our "In-Dash" integration requirements on our website).  This wired package will have everything you need to install the camera on a "camera prepped" RV and also a universal bracket that will work on any trailer.  A 30 ft cable can be ran from your hitch to the camera and then simply plugs into the receptacle when the trailer is connected. This is the easiest to install and most affordable in-dash wired camera available.

CAMERA SPECIFICATIONS
* Resolution: 1080p HD Resolution
* Lens: 2.1 mm
* Viewing Angle: 120 degree
* Durability Rating: IP69k
* Frame Rate: 60 FPS
* Night Vision: Yes, 2 XL IR LEDs
* Night Vision Visibility: 35 feet
* Lowest Operating Temperature: -20 C or -4 F

FORD SUPER DUTY REQUIREMENTS
* 2017-2025 Model Years
* Must be equipped with Ultimate Trailer Tow System (Option 874)
* Must have Sync 3 with 8" screen or Sync 4 with 12" screen
* Compatible on XL, XLT, and Lariat trim levels with Ultimate Trailer Tow System option; Ultimate Trailer Tow System comes standard on King Ranch, Platinum, and Limited Models
* If there is no receptacle, a Ford Compatible Harness is available

RAM / MOPAR HD REQUIREMENTS
* 2020-2025 Model Years
* Must be equipped with Aux Camera Prep Package (Option Code XFQ)
* Must have UConnect System with 8.4" or 12" Screen
* Compatible on Laramie, Limited, Limited Longhorn, Lone Star, Rebel, TRX, Tradesman, and Big Horn
* A RAM-compatible harness is available for certain RAM chassis
* Dealer programming may be required if not equipped from the factory
